CI-HC8B and CI-HC10B

The CI-HC8B and HC10B, our 8″ and 10″ Hidden within Cabinet (“HC”) subwoofer system, offers the highest level of performance when the installation environment requires positioning the subwoofer inside a concealed cabinet.  The proprietary downward firing bandpass design delivers ultra-clean bass frequencies with higher SPL’s by concentrating the output through a vented slot located in the bottom of the enclosure.  Simply put, the bass output which will ultimately fire through a finished toe kick system be will rich and vibrant complimenting even the most discerning speaker systems.

Features:

  • Downward-firing bandpass design
  • Slotted vent for optimal bass extraction
  • Delivers clean bass through an installed toe kick system
  • Large rubber isolation feet provided
  • Gasket tape provided to further isolate the enclosure from the cabinet construction
  • Custom sizes available to match most custom cabinet openings
CI-HC8B
SPECS DESCRIPTION SPECS
SYSTEM DESIGN Subwoofer, Down firing vented tuned slot (2″ x 10″), Bandpass
DRIVER 8″ Peerless SLS long throw driver
AMPLIFIER 300 W RMS
FREQUENCY RESPONSE / MAX SPL  35 Hz – 120 Hz / 105 spl
SENSITIVITY  92 db @ 1 watt
DIMENSIONS 14″ h x 12″ d x 12″ w (custom sizes available)
Standard FINISH Flat black formica
CI-HC10B
SPECS DESCRIPTION SPECS
SYSTEM DESIGN Subwoofer, Down firing vented tuned slot (2.5″ x 10″), Bandpass
DRIVER 10″ Proprietary high-performance long throw driver
AMPLIFIER 300 W RMS
FREQUENCY RESPONSE / MAX SPL  32 Hz – 120 Hz / 108 spl
SENSITIVITY  94 db @ 1 watt
DIMENSIONS  14″ h x 14″ d x 14″ w (custom sizes available)
Standard FINISH Flat black formica
