Any CI-Series In-wall speaker can also be converted to an On-wall, Soundbar, Bookshelf, or Tower form factor.
Cinema Reference Monitor
CI-IWHDMON
Delivers monitor quality high-resolution sound, with the room filling power of a traditional LCR.
Multi-Channel
CI-IW55
Premium grade in-wall speaker system designed to optimize multi-channel installations in rooms under 300 sq ft.
Tri-Array Surrounds
CI-IWSUR6.1 / SUR5.2
Dedicated side and rear channel speaker for high-end 5.1 and 7.1 theater applications.
Small Format
CI-IW6/IW8
Two-way compact sized in-wall loudspeaker systems capable of extremely high sound pressure levels, while maintaining true sonic fidelity.
Large Format Reference
CI-IWHDLCR / XL
State-of the-art in-wall system designed for reference level applications.
FEATURES
SOUND DEADENING ACOUSTIC TREATMENT
Our sound deadening acoustic treatment is a proprietary, approximately .114″ thick, butyl latex/silica material that is applied with a heavy paintbrush to the inside of our CI-IWHDLCR and CI-IWHDMON speakers (additional models available upon request). It cures, over a 2-week period, to a compliant, resonance suppressing system that dissipates unwanted internal reflections based upon specific factors.
- Its coarse, uneven, texture emulates a “moon-like” surface, creating multiple incident angles and crevices, reducing reflected energy via friction and turbulence.
- High density, of nearly 70 lbs/cu. ft., allows it to work effectively at mid-bass and lower midrange frequencies, below 300 Hz, where fiberglass and normal interior fibrous fill material are ineffective.
- Its rubbery like post-cure texture has a very fast decay rate and low transmission velocity, acting as an acoustic damper.
The sonic result is cleaner and more defined dialogue, string bass, woodwinds, and lower frequency piano registers with enhanced dynamics and enhanced upper-bass fill for movie soundtracks.
CUSTOM SIZES/ COLORS/ FORMATS
All speakers may be custom sized to fit existing or unique locations.
Choose from a wide array of color match options to integrate into any interior environment.
Alternate speaker orientations and designs are available upon request, including on-wall, tower and bookshelf versions.
ENCLOSURES/ WIRING
All “Cl” series models come standard with high-quality acoustic back boxes and spring binding posts.
PRE-CONSTRUCTION BRACKETS
High-quality 3/8″ MDF and perforated metal wings construction, not plastic!
